TP460 Auto Coiling & Wrapping Machine for Cable

TP460 Auto Coiling & Wrapping Machine for Cable

Feature:
1. PLC & HMI control program are used for automatic operation.

2. Wire will be coiled and packaged one by one, production with high speed.

3. It has auto adjust type coil-holding arm, without manual adjustments.
4. Parameters can be set on the control program with English.

5. With auto labeling machine, which do not need label by manual, more safe and convenience.

6. Can connect with auto stacking system & auto pallet stacking system.

7. When problem come out, the machine can auto detect the mistaked, and send message to warn the operator.
8. Cable coil OD and coil cutting length can be adjustable according to the setting parameter.
9. Cable inner Dia. can be changed according required.

10. Film Wrapping Tension can be changed as setting.

11. Cable Coil Wrapping Film material PP/PE/PVC/stretch film....

Type

Width

O.D (MM)

I.D (MM)

Wire Dia. (mm)

Packing Material

Speed

TP460

60-100

240-460

170-220

4-12

PVC

2-2.6Coil/M

TP600

80-160

32-600

200-300

5-18

PVE

1.5- 2 Coil/M
