Vertical Accumulator Frame
1. Machine type: Vertical
2. Accumulator Volume of wire ：about 120M。
3. Track length: About2M
4. Accumulator Wheel: 10/11 wheel group,ψ300mm,V shape Groove ,aluminum alloy, Surface by Anodic hardening treatment。
5. Drive：1.5KW AC Motor + reducer +10Kg magnetic powder tension controller
6. Displacement detection signal:precision Angle detection device for the whole process
7. Accumulator to hold at least 50m of cable depending how quick the completed coil can be ejected from the coiling head and new coiling can start. The length of 50m is based on a 0.5min changeover.
