Feature:
1. The barrel&screw with high output.
2. According to the extrusion material, choose the match special barrel & screw such as PVC,PE,LSNH,Teflon,Nylon etc.
3. Cross head clamper use double teeth pole chain driven,fixed parts has the functioning of auto-centring.
4. Operation plate of main control box mounted with human-computer interface & traditional button switch.
5. Electric circuit control use Mistubishi programmable controller(PLC).
6. Transducer use Mistubishi FR-A740 series.
7. Tem-control use Japanese RKC series tem-controller &solidity repay(SSR).
8. Hopper dryer& Auto-suction device use imported famous Brand.
Technical Information:
Type | Screw Date | Extrude Capacity (Kg/HrMax) | Out Dia.(mm) | Motor(KW) | ||||
Dia(mm) | L/D | Speed(RPM) | PVC | LDPE | LSNH | 0.8-3 | ||
EX-40G | 40 | 26:1 | 120 | 24 | 14 | 1-6 | 11 | |
EX-50G | 50 | 26:1 | 120 | 60 | 35 | 2-8 | 15 | |
EX-60G | 60 | 26:1 | 120 | 100 | 60 | 22 | 3-15 | 22 |
EX-70G | 70 | 26:1 | 120 | 160 | 130 | 36 | 5-20 | 30 |
EX-80G | 80 | 26:1 | 110 | 220 | 180 | 48 | 8-25 | 37 |
EX-90G | 90 | 26:1 | 100 | 310 | 240 | 65 | 10-30 | 55 |
EX-100G | 100 | 25:1 | 90 | 400 | 90 | 15-40 | 55 | |
EX-120G | 120 | 25:1 | 90 | 550 | 90 | |||
EX-150G | 150 | 25:1 | 60 | 900 | 550 | 200 | ||
EX-200G | 200 | 25:1 | 60 | 1300 | 1100 | 750 | 280(315) | |
