Rigid Frame Strander

Product details

Rigid Frame Strander:

The machine (with lumped loading device) is suitable for producing large length, compact ,bare Al/Cu wire, and ACSR, aluminum alloy wire and sector conductor. The machine is driven by separate motor for each cage and dual capstan; the stranding pitch can be adjusted by Touch screen.

Line Main Parts:

Payoff	1set
Wire Guider	1set
Stranding cage 6B,12B, 18B, 24B, 30B, 36B	Each 1set
single wire pre-twisted	Each 1set
Wire Closing and Press mold base	Each 1set
Meter Counter	1set
Double wheel capstan 2000/2500	1set
Side/bottom Lumped loading system	3set
Take up	1set
Electric control system	1set

Main Technical Date:

Machine Model	JLK-630	JLK-710
Single Copper Wire Dia.	Φ1.7～Φ4.5mm	Φ1.7～Φ4.5mm
Single Alumium Wire Dia.	Φ1.8～Φ5.0mm	Φ1.8～Φ5.0mm
Single Alumium Alloy Wire Dia.	Φ1.7～Φ4.5mm	Φ1.7～Φ4.5mm
Max. stranded wire dia.	Φ30-55mm	Φ30-55mm
Lay length	40～350mm(step-less adjust)	40～350mm(step-less adjust)
Max rotate speed	500rpm	500rpm
Max line speed	100m/min	100m/min
Max rewinding speed	150～200m/min	150～200m/min
Pay off in Cage	630	710
Centre Payoff	PND630/1600	PND630/1600
Dual Wheel Capstan	2000mm, 2500mm	2000mm, 2500mm
Cage rotate motor	Siemens AC Motor	Siemens AC Motor
Stranding Cage Structure	6B, 12B, 18B, 24B, 30B, 36B	6B, 12B, 18B, 24B, 30B, 36B
Loading Method	Side loading or Bottom loading	Side loading or Bottom loading
